Fusion Energy Applications

Magnetic Confinement Fusion (MCF)

Peak NanoPlex™ capacitor films deliver faster, stable pulses at high temperatures, with fewer components and longer life for magnetic fusion.

Request a Sample Kit

NanoPlex™ High Current Capacitors for Magnetic-Coil Drivers

NanoPlex LDF is engineered for magnetic fusion systems that demand high-frequency, high-heat, high-performance pulse delivery. With full energy capacity at 135°C and a low-loss, high-stability architecture, LDF capacitors enable faster shot repetition for injection systems, tighter control, and reduced system complexity, without the thermal, space, or maintenance limitations of traditional banks.

  • Full energy, zero derating under extreme heat and pulse load
  • Shorter recovery times boost throughput and consistency
  • Low self-heating reduces fans, cooling systems, and energy waste
  • Extended duty under high stress cuts downtime and O&M costs

Precision Firing Without Downtime or Derating

  • During a fusion pulse, capacitor banks must deliver high current through magnetic field coils that confine the plasma. This generates extreme heat. Traditional BOPP films lose performance above 85°C, compromising energy delivery and reducing pulse precision as repetition rates rise.
  • NanoPlex LDF maintains full energy capacity up to 135°C without derating, handling intense, repeated fusion shots without drifting or degrading - no oversizing or additional cooling systems required.
  • Fusion teams get stable, precise performance, even under high heat and heavy load, so they can repeat shots more consistently, improve energy yield, and speed up progress toward commercial fusion.

Engineered for Repetition, Stable Operation at Scale

  • As magnetic-fusion systems push toward higher repetition rates, capacitor banks must charge and discharge in rapid succession. Conventional films degrade quickly under this stress, limiting performance and increasing downtime.
  • NanoPlex LDF features a low-loss architecture that enables up to 4x faster charge and discharge compared to conventional film. This supports more consistent, high-frequency operation without thermal or structural breakdown.
  • Shorter recovery times between pulses allow fusion teams to run faster shot sequences, boost pulse reliability, and maintain consistent performance, without increasing replacement cycles or maintenance load.

NanoPlex™ LDF Capacitors Last Longer in High Temperatures

  • With each pulse, conventional BOPP capacitors build internal heat. As temperatures rise past 85°C, they begin to lose capacitance, forcing engineers to add fans, heat sinks, or extra capacitors just to stay within safe limits.
  • NanoPlex LDF capacitors have a 50% lower dissipation factor than conventional film, producing less self-heating during operation. They remain stable at higher temperatures, even under repeated pulsing.
  • Fusion teams can reduce their cooling systems, save energy, and simplify thermal design, without sacrificing performance. This means more stable operation, fewer components, and better long-term reliability.

Stores More Energy Per Capacitor

  • To meet modern energy demands, conventional films require more capacitors and longer wiring runs. This inflates system size, increases cost, and makes precise pulse delivery harder to manage.
  • NanoPlex LDF holds full capacitance up to 135°C, allowing fusion teams to use fewer capacitors without sacrificing performance. Systems are designed to stay cooler and more compact.
  • Fewer components mean easier installation, reduced material costs, and better pulse control. It also simplifies service and opens the door for more scalable, future-ready fusion systems.

Longer LifeSpan, Less Downtime

  • In fusion systems, repeated heat cycles and electrical pulsing cause BOPP-based capacitors to degrade, leading to frequent replacements, more downtime, and higher maintenance costs.
  • NanoPlex LDF maintains full energy capacity up to 135°C and resists thermal and electrical fatigue, providing stable, long-term performance under sustained pulsed-power operation.
  • Fusion teams can reduce scheduled outages, keep systems online longer, and lower total O&M costs, extending service life without compromising performance in high-duty environments.

NanoPlex™ LDF vs. Traditional BOPP Film for Magnetic Fusion Systems

NanoPlex LDF gives magnetic fusion teams a smarter capacitor film option - designed for higher shot rates, higher temperatures, and longer runtimes - all in a smaller, cooler, and more cost-effective package.

Capability Traditional BOPP Film NanoPlex LDF Film
Temperature Stability Starts derating above 85°C, reducing energy delivery Operates at full capacitance up to 135°C with no derating
Pulse Stability Drift and degradation at high duty cycles require oversizing Maintains consistent performance under high repetition and heat
Charge/Discharge Speed Slower cycling under stress; limited support for high-frequency operation Up to 4x faster charge and discharge; shorter recovery times
Thermal Management Generates more heat; needs additional fans, heat sinks, or capacitors 50% lower dissipation factor; reduced heat generation and cooling needs
Energy Efficiency Requires more components and longer wiring to meet the same energy goals Stores more energy with fewer capacitors; supports compact layouts
System Footprint Larger, heavier banks complicate integration and increase system size Enables capacitor banks that are 50% smaller and 30% lighter
Service Life Frequent replacements; higher O&M and downtime Lasts up to 5x longer under thermal and electrical stress
Cost Efficiency Higher install cost due to more parts and thermal management components Cuts BOM costs by up to 60% through fewer parts and simpler design
Pulse Consistency Pulse degradation over time and under heat stress Tighter control for repeatable, high-energy pulses
Scalability Limited by thermal ceiling and component count Designed for future-ready, high-rep-rate fusion systems
nanoplex-logo-white

Ready to Evaluate NanoPlex films?

Request a sample kit for in-house testing, compatibility evaluation, and high-pulse performance validation in magnetic fusion systems.

Request a Sample Kit

Frequently Asked Questions for Magnetic Fusion

Suppliers often search for materials that maintain full capacitance at high duty cycles. NanoPlex LDF films, for instance, operate up to 135°C with no derating, making them ideal for magnetic fusion capacitor banks that face rapid cycling and intense heat.

Fusion suppliers want compact, thermally stable systems. LDF films offer up to 4x higher energy density and 50% less heat loss than BOPP, enabling smaller banks with reduced cooling systems, lowering overall footprint and cost.

Pulse stability is critical for confinement accuracy. Advanced films like NanoPlex LDF provide consistent energy delivery under heat and stress, improving synchronization and repeatability during high-frequency operation.

Suppliers value reliability and uptime. NanoPlex LDF lasts up to 5x longer than conventional films, resisting thermal and electrical fatigue. This reduces maintenance windows and extends overall service life in high-duty environments.

With over 70% of traditional film production located overseas, U.S.-made films like NanoPlex LDF ensure reliable access, shorter lead times, and compliance with national security and Buy American priorities, critical for fusion-scale manufacturing.
